#21d Z80 CPU + Clock Module
Description
- Z80 CPU
- Crystal up to 20Mhz
- 51 x 102 mm
- RC40 bus connector
Components
- PCB - 21d
- DIP-40 socket
- Z80 CPU Z84C0020PEC
- DIP-14 socket
- 74HCT04
- 10k resistors (5x)
- 1M resistor
- 1K resistor
- 100nF capacitors (2x)
- 22pF capacitors (2x)
- crystal (7.3728Mhz - 20 Mhz)
- 1x2 pin male pin header (2x)
- jumper (1 or 2)
- 40 + 10 pin angled male connector
